OGL-051-G3-T3 di-soric 50 x 50 mm L-Shaped / Angled Fork Visible Red Light Barrier, Push/Pull 100 mA NO/NC, IO-Link

The OGL-051-G3-T3 di-soric 50 × 50 mm L-shaped / angled fork visible red light barrier is designed for precise object, edge, label, and small-part detection where the sensor must be mounted around the process instead of directly in line with it. Its angled fork geometry provides a 50 mm fork opening with a 50 mm internal leg length, helping solve mounting and access constraints in compact packaging, assembly, handling, and automation equipment.

This model uses a visible red LED light source with 0.3 mm resolution for accurate detection of small, opaque, reflective, and semi-transparent targets. The push/pull 100 mA NO/NC output, IO-Link interface, M8 3-pin connection, and IP67 zinc housing make the OGL-051-G3-T3 a strong choice where repeatable sensing, setup flexibility, diagnostics, and reliable operation are required in a compact angled fork sensor.

Key Features & Advantages

• 50 × 50 mm L-shaped fork geometry: Provides a 50 mm fork opening with 50 mm internal leg length for angled mounting around machine parts, conveyors, label paths, or handling areas.
• Visible red LED light source: Helps with alignment and setup while providing reliable through-beam detection across the fork opening.
• 0.3 mm resolution: Supports fine detection of small parts, edges, labels, webs, and other targets requiring precise switching.
• Push/pull 100 mA NO/NC output: Flexible switching output for integration with common machine controls and PLC inputs.
• IO-Link interface: Enables parameterization, diagnostics, status monitoring, and simplified setup where IO-Link is used.
• 5000 Hz switching frequency: Suitable for high-speed counting, positioning, edge detection, and fast-moving automation processes.
• IP67 zinc housing with M8 3-pin connection: Rugged compact construction for machine-mounted industrial sensor installations.

Typical Applications

• Label and edge detection on packaging, converting, and print machinery
• Small-part detection in assembly and handling systems
• Position sensing for moving machine parts, carriers, or product guides
• Object detection where an angled or L-shaped sensor body improves access
• Counting, presence detection, and part verification in compact automation equipment
• Detection of opaque, reflective, and semi-transparent targets

Ideal For

The OGL-051-G3-T3 is well suited for OEMs, machine builders, MRO teams, and system integrators that need a compact 50 × 50 mm di-soric angled fork light barrier with visible red LED sensing, fine resolution, push/pull output, and IO-Link capability.
