5020.037.250 / 15020037250 RQG-M M50 x 1.5 mm Metric FLEXAquick® Black straight connector for 54.5 mm OD conduit, IP68 sealing

Product Name:
5020.037.250 / 15020037250 RQG-M M50 x 1.5 mm Metric FLEXAquick® Black straight connector for 54.5 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020037250 Categories , , ,

The Flexaquick® RQG-M 15020037250 (Old Part Number 5020.037.250) is a straight Black plastic conduit connector with metric M50 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Choose from over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.





In Stock: 4
Stock: 4 can ship immediately
Factory Lead-Time: Can ship in 1 – 2 weeks
Minimum: 1
Multiples: 1

4 in stock

Quantity Unit Price Ext. Price
1 US$28.36 US$28.36
5 US$25.52 US$127.62
10 US$22.69 US$226.88
20 US$21.27 US$425.40
50 US$19.85 US$992.60
100+ US$18.43 US$1,843.40+
Unit Cost : US$
Extended Cost : US$28.36
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-M
Part Number

15020037250
Part Number (Old)

5020.037.250
Colour

Black
Thread Type

Metric
Thread Size

M50 x 1.5
Thread Length C (mm)

17
Body Length D (mm)

88
Material

PA6 Plastic
OD Outside Diameter (mm)

54.5
ΦI Inside Diameter (mm)

42.5
ΦB Max Outer Diameter (mm)

68
Weight (kg|100)

8.3
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148438

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
