5020.057.207 / 15020057207 RQW-N 1 1/4” NPT FLEXAquick® black 90° elbow connector for 42.5 mm OD conduit, IP68 sealing

Product Name:
5020.057.207 / 15020057207 RQW-N 1 1/4” NPT FLEXAquick® black 90° elbow connector for 42.5 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020057207 Categories , , ,

The Flexaquick RQW-N 15020057207 (Old Part Number 5020.057.207) is a Black plastic 90° elbow conduit connector with 1 1/4″ NPT outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-N 1 1/4″ NPT 90° elbow fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). View over 20 varieties of ROHRflex corrugated nylon conduits.



In Stock: 12
Stock: 12 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

12 in stock

Quantity Unit Price Ext. Price
1 US$39.97 US$39.97
5 US$35.97 US$179.87
10 US$31.98 US$319.76
20 US$29.98 US$599.55
50 US$27.98 US$1,398.95
100+ US$25.98 US$2,598.05+
Unit Cost : US$
Extended Cost : US$39.97
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQW-N
Part Number

15020057207
Part Number (Old)

5020.057.207
Colour

Black
Thread Type

NPT
Thread Size

1 1/4"
Thread Length C (mm)

18
Body Length D (mm)

83
Body Length E (mm)

76
Material

PA6 Plastic
OD Outside Diameter (mm)

42.5
ΦI Inside Diameter (mm)

35
ΦB Max Outer Diameter (mm)

52
Weight (kg|100)

6.9
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113174628

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
