5020.036.063 / 15020036063 RQW-M M63 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 54.5 mm OD conduit, IP68 sealing

Product Name:
5020.036.063 / 15020036063 RQW-M M63 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 54.5 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020036063 Categories , , ,

The Flexaquick® RQW-M 15020036063 (Old Part Number 5020.036.063) is a Grey plastic 90° elbow conduit connector with metric M63 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Find the right conduit solution from over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$48.09 US$48.09
5 US$38.47 US$192.36
10 US$37.51 US$375.10
25 US$36.07 US$901.69
50 US$33.66 US$1,683.15
100+ US$31.26 US$3,125.85+
Unit Cost : US$
Extended Cost : US$48.09
Add to Quote

Specifications

Package Size

5 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQW-M
Part Number

15020036063
Part Number (Old)

5020.036.063
Colour

Grey
Thread Type

Metric
Thread Size

M63 x 1.5
Thread Length C (mm)

16
Body Length D (mm)

94
Body Length E (mm)

85.5
Material

PA6 Plastic
OD Outside Diameter (mm)

54.5
ΦI Inside Diameter (mm)

53
ΦB Max Outer Diameter (mm)

64
Weight (kg|100)

10.8
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148209

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
