5020.036.025 / 15020036025 RQW-M M25 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 21.2 mm OD conduit, IP68 sealing

Product Name:
5020.036.025 / 15020036025 RQW-M M25 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 21.2 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020036025 Categories , , ,

The Flexaquick® RQW-M 15020036025 (Old Part Number 5020.036.025) is a Grey plastic 90° elbow conduit connector with metric M25 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Find the right conduit solution from over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.



In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 CAD$14.64 CAD$14.64
5 CAD$14.20 CAD$70.99
10 CAD$13.91 CAD$139.06
15 CAD$13.17 CAD$197.61
25 CAD$12.44 CAD$311.05
50 CAD$11.71 CAD$585.50
100 CAD$10.98 CAD$1,097.81
250 CAD$10.25 CAD$2,561.56
500+ CAD$9.51 CAD$4,757.19+
Unit Cost : CAD$
Extended Cost : CAD$14.6375
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQW-M
Part Number

15020036025
Part Number (Old)

5020.036.025
Colour

Grey
Thread Type

Metric
Thread Size

M25 x 1.5
Thread Length C (mm)

13
Body Length D (mm)

50
Body Length E (mm)

49
Material

PA6 Plastic
OD Outside Diameter (mm)

21.2
ΦI Inside Diameter (mm)

18
ΦB Max Outer Diameter (mm)

29.5
Weight (kg|100)

1.9
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148162

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
