5020.036.020 / 15020036020 RQW-M M20 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 15.8 mm OD conduit, IP68 sealing

Product Name:
5020.036.020 / 15020036020 RQW-M M20 x 1.5 mm Metric FLEXAquick® Grey 90 degree elbow connector for 15.8 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020036020 Categories , , ,

The Flexaquick® RQW-M 15020036020 (Old Part Number 5020.036.020) is a Grey plastic 90° elbow conduit connector with metric M20 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Find the right conduit solution from over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$10.50 US$10.50
5 US$10.19 US$50.93
10 US$9.98 US$99.75
15 US$9.45 US$141.75
25 US$8.93 US$223.13
50 US$8.40 US$420.00
100 US$7.88 US$787.50
250 US$7.35 US$1,837.50
500+ US$6.83 US$3,412.50+
Unit Cost : US$
Extended Cost : US$10.5
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQW-M
Part Number

15020036020
Part Number (Old)

5020.036.020
Colour

Grey
Thread Type

Metric
Thread Size

M20 x 1.5
Thread Length C (mm)

13
Body Length D (mm)

42
Body Length E (mm)

41.5
Material

PA6 Plastic
OD Outside Diameter (mm)

15.8
ΦI Inside Diameter (mm)

15.5
ΦB Max Outer Diameter (mm)

23
Weight (kg|100)

1.1
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148155

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
