5107.442.240 / 15107442240 RQGK-M M40 x 1.5 mm FLEXAquick® straight metal short thread connector for 42.5 mm OD conduit

Product Name:
5107.442.240 / 15107442240 RQGK-M M40 x 1.5 mm FLEXAquick® straight metal short thread connector for 42.5 mm OD conduit

Flexa Logo
Mfr. Part # 15107442240 Categories , , ,

The Flexaquick RQGK-M 15107442240 (Old Part Number 5107.442.240) is a straight Black plastic conduit connector with metric M40 x 1.5 mm nickel-plated brass short thread.

Thread length is 8.0 mm. Included with the fitting are both a Nitrile O-ring (OR-M) and a green Centellen flat sealing washer (FRH-M) for IP68/69K thread sealing.

The RQGK-M features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQGK-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.



In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 CAD$75.91 CAD$75.91
5 CAD$68.31 CAD$341.57
10 CAD$60.72 CAD$607.24
20 CAD$56.93 CAD$1,138.58
50 CAD$53.13 CAD$2,656.68
100+ CAD$49.34 CAD$4,933.83+
Unit Cost : CAD$
Extended Cost : CAD$75.905
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGK-M
Part Number

15107442240
Part Number (Old)

5107.442.240
Colour

Black
Thread Type

Metric
Thread Size

M40 x 1. 5
Thread Length C (mm)

8. 0
Body Length D (mm)

67. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

42. 5
ΦI Inside Diameter (mm)

32. 0
ΦB Max Outer Diameter (mm)

58. 0
Weight (kg|100)

7.7
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113261281

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
