5107.054.263 / 15107054263 RQGK-M M63 x 1.5 mm FLEXAquick® straight metal thread connector for 54.5 mm OD conduit

  • 5107.054.263 / 15107054263 RQGK-M M63 x 1.5 mm FLEXAquick® straight metal thread connector for 54.5 mm OD conduit

Product Name:
5107.054.263 / 15107054263 RQGK-M M63 x 1.5 mm FLEXAquick® straight metal thread connector for 54.5 mm OD conduit

Flexa Logo
Mfr. Part # 15107054263 Categories , , ,

The Flexaquick RQGK-M 15107054263 (Old Part Number 5107.054.263) is a straight Black plastic conduit connector with metric M63 x 1.5 mm nickel-plated brass thread.

Thread length is 17.0 mm. Included with the fitting are both a Nitrile O-ring (OR-M) and a green Centellen flat sealing washer (FRH-M) for IP68/69K thread sealing.

The RQGK-M features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQGK-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.



In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Available 750 pieces +/- April 10th, book now
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$84.94 US$84.94
5 US$76.45 US$382.23
10 US$67.95 US$679.52
20 US$63.71 US$1,274.10
50 US$59.46 US$2,972.90
100+ US$55.21 US$5,521.10+
Unit Cost : US$
Extended Cost : US$84.94
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGK-M
Part Number

15107054263
Part Number (Old)

5107.054.263
Colour

Black
Thread Type

Metric
Thread Size

M63 x 1. 5
Thread Length C (mm)

17. 0
Body Length D (mm)

88. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

54. 5
ΦI Inside Diameter (mm)

49. 0
ΦB Max Outer Diameter (mm)

74. 0
Weight (kg|100)

23
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113212023

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
