5107.042.250 / 15107042250 RQGK-M M50 x 1.5 mm FLEXAquick® straight metal thread connector for 42.5 mm OD conduit

Product Name:
5107.042.250 / 15107042250 RQGK-M M50 x 1.5 mm FLEXAquick® straight metal thread connector for 42.5 mm OD conduit

Flexa Logo
Mfr. Part # 15107042250 Categories , , ,

The Flexaquick RQGK-M 15107042250 (Old Part Number 5107.042.250) is a straight Black plastic conduit connector with metric M50 x 1.5 mm nickel-plated brass thread.

Thread length is 17.0 mm. Included with the fitting are both a Nitrile O-ring (OR-M) and a green Centellen flat sealing washer (FRH-M) for IP68/69K thread sealing.

The RQGK-M features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQGK-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.



In Stock: 10
Stock: 10 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

10 in stock

Quantity Unit Price Ext. Price
1 US$56.01 US$56.01
5 US$50.41 US$252.05
10 US$44.81 US$448.08
20 US$42.01 US$840.15
50 US$39.21 US$1,960.35
100+ US$36.41 US$3,640.65+
Unit Cost : US$
Extended Cost : US$56.01
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGK-M
Part Number

15107042250
Part Number (Old)

5107.042.250
Colour

Black
Thread Type

Metric
Thread Size

M50 x 1. 5
Thread Length C (mm)

17. 0
Body Length D (mm)

76. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

42. 5
ΦI Inside Diameter (mm)

37. 5
ΦB Max Outer Diameter (mm)

63. 0
Weight (kg|100)

14.5
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113211934

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
