5010.227.029 / 15010227029 Flexa USW-P PG29 nickel-plated brass 90° elbow connector for 36.0 mm OD conduit

Product Name:
5010.227.029 / 15010227029 Flexa USW-P PG29 nickel-plated brass 90° elbow connector for 36.0 mm OD conduit

Flexa Logo
Mfr. Part # 15010227029 Categories , ,

The Flexa USW-P 15010227029 (Old Part Number 5010.227.029) is a PG29 threaded 90° elbow conduit connector made of nickel-plated brass.

This rugged, high-quality, machined conduit fitting boasts the following features:

Use with the following Flexa conduits (IP40 sealing):

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1 – 2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$159.71 US$159.71
5 US$143.74 US$718.70
10+ US$127.77 US$1,277.68+
Unit Cost : US$
Extended Cost : US$159.71
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Metal Body Fitting
Brand

Flexa
Family

USW-P
Part Number

15010227029
Part Number (Old)

5010.227.029
Fits Conduit Types

FLEXAgraff-AS, FLEXAgraff-VA, SPR-AS, SPR-VA
Thread Type

PG
Thread Size

PG29
Thread Length C (mm)

11
Body Length D (mm)

72
Material

Ni-Brass
OD Outside Diameter (mm)

36
ΦI Inside Diameter (mm)

29.5
ΦB Max Outer Diameter (mm)

48
Weight (kg|100)

23.3
IP Rating

IP 40
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

125

Data Sheet

Properties

  • highly watertight and dustproof
  • friction-type locking of conduit and screw connector
  • correct grounding
  • covering of the conduit ends
  • vibration and tension proof

Applications

  • machine and plant constructions
  • automotive
  • railway industry
  • automation
  • shipbuilding
  • electrical installations

Certifications
