lpc+25/WK/CFU Microsonic 30 – 350 mm range, Ultrasonic Distance Measuring Sensor, 90° sensing head, 1 x Push/Pull, 1 x analogue 0-10 V outputs, IO-Link

Product Name:
lpc+25/WK/CFU Microsonic 30 – 350 mm range, Ultrasonic Distance Measuring Sensor, 90° sensing head, 1 x Push/Pull, 1 x analogue 0-10 V outputs, IO-Link

Mfr. Part # lpc+25/WK/CFU Categories , ,

The Microsonic Cylindrical Body lpc+25/WK/CFU is a 30 – 350 mm range Ultrasonic Distance Measuring Sensor, 90° sensing head, 1 x analog 0-10 V and 1 x Push/Pull outputs, M18 housing, IO-Link enabled.

Highlights:

  • 90° Sensing Head, handy for tight sensing locations
  • 0 – 350 mm
  • 1 x Analogue 0-10 V output
  • 1 x Push/Pull output
  • IO-Link interface
  • Simple programming via a IO-Link or Teach-in input on pin 5 with LinkControl
  • Resolution 0.10 mm
  • Easy mounting M18 nickel-plated brass housing with M12 – 5 pin plug connector. IP67 sealing

Applications: The IO-Link ready lpc+25/WK/CFU sensor is loaded with features and a good choice for many applications like paper feed stack detection in packaging machines, roll diameter monitoring in paper converting, tank liquid or bin pellet fill level monitoring, bottle detection, and any application where continuous measurement of varying or moving targets is needed.

In Stock: 0
Factory Lead-Time: Can ship in 1 – 2 weeks
Quantity Unit Price Ext. Price
1+ US$0.00 US$0.00+
Unit Cost : US$
Extended Cost : US$0
Add to Quote

Specifications

Product Type

Sensors
Brand

Microsonic
Family

Cylindrical Body
Part Number

lpc+25/WK/CFU
Model ID Number

36121
Resolution

0.10 mm
Housing Material

Nickel-plated Brass
Weight (g)

40
Switching Output

Analog 0-10 V | Push-pull 100 mA | NO/NC
Interface

IO-Link
Connection

M12 | 5-pin
IP Rating

IP67
Operating Temperature Range

-25 to +70 °C
Supply Voltage

+10 to 30 VDC
Sensing Distance

350 mm
Body Size

M18

Data Sheet

Overview

  • Full details coming soon
