5020.032.209 / 15020032209 RQY-PA 34.5 / 2 x 28.5 mm FLEXAquick® black plastic “Y” distributor fitting for corrugated conduits

Product Name:
5020.032.209 / 15020032209 RQY-PA 34.5 / 2 x 28.5 mm FLEXAquick® black plastic “Y” distributor fitting for corrugated conduits

Flexa Logo
Mfr. Part # 15020032209 Categories , , ,

The Flexaquick RQY-PA 15020032209 (Old Part Number 5020.032.209) is a 34.5 / 2 x 28.5 mm OD Black plastic “Y” fitting for corrugated conduits.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQY-PA “wye” conduit connector with all fine or coarse corrugation plastic conduits of matching outside diameter (OD).

In Stock: 26
Stock: 26 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

26 in stock

Quantity Unit Price Ext. Price
1 CAD$33.99 CAD$33.99
5 CAD$30.60 CAD$152.98
10 CAD$27.20 CAD$271.96
20 CAD$25.50 CAD$509.92
50 CAD$23.80 CAD$1,189.81
100+ CAD$22.10 CAD$2,209.66+
Unit Cost : CAD$
Extended Cost : CAD$33.9947
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQY-PA
Part Number

15020032209
Part Number (Old)

5020.032.209
Colour

Black
Body Length C (mm)

77. 5
Body Length D (mm)

106. 0
Body Length E (mm)

43. 0
Material

PA6 Plastic
OD 1 (mm)

34. 5
OD 2 (mm)

2 x 28. 5
ΦB1 (mm)

44. 0
ΦB2 (mm)

37. 0
Mounting Hole ΦF

6. 5
Weight (kg|100)

7.7
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113212849

Data Sheet

Applications

  • For Static and Dynamic Applications Indoor and Outdoor of Railway Cars
  • Heavy Machine and Plant Constructions
  • Insulated Electrical Installations

Certifications
