5020.032.203 / 15020032203 RQY-PA 15.8 / 2 x 13.0 mm FLEXAquick® black plastic “Y” distributor fitting for corrugated conduits

Product Name:
5020.032.203 / 15020032203 RQY-PA 15.8 / 2 x 13.0 mm FLEXAquick® black plastic “Y” distributor fitting for corrugated conduits

Flexa Logo
Mfr. Part # 15020032203 Categories , , ,

The Flexaquick RQY-PA 15020032203 (Old Part Number 5020.032.203) is a 15.8 / 2 x 13.0 mm OD Black plastic “Y” fitting for corrugated conduits.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQY-PA “wye” conduit connector with all fine or coarse corrugation plastic conduits of matching outside diameter (OD).

In Stock: 28
Stock: 28 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

28 in stock

Quantity Unit Price Ext. Price
1 US$17.14 US$17.14
5 US$15.43 US$77.13
10 US$13.71 US$137.12
20 US$12.86 US$257.10
50 US$12.00 US$599.90
100+ US$11.14 US$1,114.10+
Unit Cost : US$
Extended Cost : US$17.14
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQY-PA
Part Number

15020032203
Part Number (Old)

5020.032.203
Colour

Black
Body Length C (mm)

42. 0
Body Length D (mm)

72. 0
Body Length E (mm)

29. 0
Material

PA6 Plastic
OD 1 (mm)

15. 8
OD 2 (mm)

2 x 13. 0
ΦB1 (mm)

23. 0
ΦB2 (mm)

20. 0
Mounting Hole ΦF

5. 5
Weight (kg|100)

2
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113212740

Data Sheet

Applications

  • For Static and Dynamic Applications Indoor and Outdoor of Railway Cars
  • Heavy Machine and Plant Constructions
  • Insulated Electrical Installations

Certifications
