5020.026.211 / 15020026211 RQG-P PG 11 FLEXAquick® black straight connector for 15.8 mm OD conduit, IP68 sealing

Product Name:
5020.026.211 / 15020026211 RQG-P PG 11 FLEXAquick® black straight connector for 15.8 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020026211 Categories , , ,

The Flexaquick RQG-P 15020026211 (Old Part Number 5020.026.211) is a straight Black plastic conduit connector with European PG 11 outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-P PG11 thread straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore the many ROHRflex multi-purpose and robotic grade corrugated nylon conduits.





In Stock: 353
Stock: 353 can ship immediately
Factory Lead-Time: Can ship in 1 – 2 weeks
Minimum: 1
Multiples: 1

353 in stock

Quantity Unit Price Ext. Price
1 US$5.72 US$5.72
5 US$5.55 US$27.74
10 US$5.43 US$54.34
15 US$5.15 US$77.22
25 US$4.86 US$121.55
50 US$4.58 US$228.80
100 US$4.29 US$429.00
250 US$4.00 US$1,001.00
500+ US$3.72 US$1,859.00+
Unit Cost : US$
Extended Cost : US$5.72
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-P
Part Number

15020026211
Part Number (Old)

5020.026.211
Colour

Black
Thread Type

PG
Thread Size

11
Thread Length C (mm)

10
Body Length D (mm)

37
Material

PA6 Plastic
OD Outside Diameter (mm)

15.8
ΦI Inside Diameter (mm)

12.5
ΦB Max Outer Diameter (mm)

23
Weight (kg|100)

0.7
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113147240

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
