5020.026.209 / 15020026209 RQG-P PG 9 FLEXAquick® black straight connector for 13.0 mm OD conduit, IP68 sealing

Product Name:
5020.026.209 / 15020026209 RQG-P PG 9 FLEXAquick® black straight connector for 13.0 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020026209 Categories , , ,

The Flexaquick RQG-P 15020026209 (Old Part Number 5020.026.209) is a straight Black plastic conduit connector with European PG 9 outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-P PG9 thread straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore the many ROHRflex multi-purpose and robotic grade corrugated nylon conduits.



In Stock: 325
Stock: 325 can ship immediately
Factory Lead-Time: Can ship in 1 – 2 weeks
Minimum: 1
Multiples: 1

325 in stock

Quantity Unit Price Ext. Price
1 CAD$5.53 CAD$5.53
5 CAD$5.36 CAD$26.82
10 CAD$5.25 CAD$52.54
15 CAD$4.98 CAD$74.66
25 CAD$4.70 CAD$117.51
50 CAD$4.42 CAD$221.20
100 CAD$4.15 CAD$414.75
250 CAD$3.87 CAD$967.75
500+ CAD$3.59 CAD$1,797.25+
Unit Cost : CAD$
Extended Cost : CAD$5.53
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-P
Part Number

15020026209
Part Number (Old)

5020.026.209
Colour

Black
Thread Type

PG
Thread Size

9
Thread Length C (mm)

10
Body Length D (mm)

35
Material

PA6 Plastic
OD Outside Diameter (mm)

13
ΦI Inside Diameter (mm)

10
ΦB Max Outer Diameter (mm)

20
Weight (kg|100)

0.5
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113147233

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
