5020.056.202 / 15020056202 RQG-N 1/4” NPT FLEXAquick® Black straight connector for 13.0 mm OD conduit, IP68 sealing

  • 5020.056.202 / 15020056202 RQG-N 1/4'' NPT FLEXAquick® Black straight connector for 13.0 mm OD conduit, IP68 sealing

Product Name:
5020.056.202 / 15020056202 RQG-N 1/4” NPT FLEXAquick® Black straight connector for 13.0 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020056202 Categories , , ,

The Flexaquick® RQG-N 15020056202 (Old Part Number 5020.056.202) is a straight Black plastic conduit connector with 1/4″ NPT outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-N 1/4” NPT straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Browse over 20 varieties of ROHRflex corrugated nylon conduits.

In Stock: 92
Stock: 92 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

92 in stock

Quantity Unit Price Ext. Price
1 US$5.52 US$5.52
5 US$5.35 US$26.77
10 US$5.24 US$52.44
15 US$4.97 US$74.52
25 US$4.69 US$117.30
50 US$4.42 US$220.80
100 US$4.14 US$414.00
250 US$3.86 US$966.00
500+ US$3.59 US$1,794.00+
Unit Cost : US$
Extended Cost : US$5.52
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-N
Part Number

15020056202
Part Number (Old)

5020.056.202
Colour

Black
Thread Type

NPT
Thread Size

1/4"
Thread Length C (mm)

9.5
Body Length D (mm)

37
Material

PA6 Plastic
OD Outside Diameter (mm)

13
ΦI Inside Diameter (mm)

10
ΦB Max Outer Diameter (mm)

20
Weight (kg|100)

0.6
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113173010

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
