5020.065.009 / 15020065009 RQG-M M25 x 1.5 mm Metric FLEXAquick® Grey straight connector for 21.2 mm OD conduit, IP68 sealing

Product Name:
5020.065.009 / 15020065009 RQG-M M25 x 1.5 mm Metric FLEXAquick® Grey straight connector for 21.2 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020065009 Categories , , ,

The Flexaquick® RQG-M 15020065009 (Old Part Number 5020.065.009) is a straight Grey plastic conduit connector with metric M25 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-M straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$10.11 US$10.11
5 US$9.81 US$49.03
10 US$9.60 US$96.05
15 US$9.10 US$136.49
25 US$8.59 US$214.84
50 US$8.09 US$404.40
100 US$7.58 US$758.25
250 US$7.08 US$1,769.25
500+ US$6.57 US$3,285.75+
Unit Cost : US$
Extended Cost : US$10.11
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-M
Part Number

15020065009
Part Number (Old)

5020.065.009
Colour

Grey
Thread Type

Metric
Thread Size

M25 x 1.5
Thread Length C (mm)

13
Body Length D (mm)

44.5
Material

PA6 Plastic
OD Outside Diameter (mm)

21.2
ΦI Inside Diameter (mm)

17
ΦB Max Outer Diameter (mm)

29.5
Weight (kg|100)

1.2
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113189806

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
