5020.037.232 / 15020037232 RQG-M M32 x 1.5 mm Metric FLEXAquick® Black straight connector for 34.5 mm OD conduit, IP68 sealing

Product Name:
5020.037.232 / 15020037232 RQG-M M32 x 1.5 mm Metric FLEXAquick® Black straight connector for 34.5 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020037232 Categories , , ,

The Flexaquick® RQG-M 15020037232 (Old Part Number 5020.037.232) is a straight Black plastic conduit connector with metric M32 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.





In Stock: 120
Stock: 120 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

120 in stock

Quantity Unit Price Ext. Price
1 US$13.26 US$13.26
5 US$12.86 US$64.31
10 US$12.60 US$125.97
15 US$11.93 US$179.01
20 US$11.27 US$225.42
25 US$10.61 US$265.20
50 US$9.95 US$497.25
100 US$9.28 US$928.20
250+ US$8.62 US$2,154.75+
Unit Cost : US$
Extended Cost : US$13.26
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-M
Part Number

15020037232
Part Number (Old)

5020.037.232
Colour

Black
Thread Type

Metric
Thread Size

M32 x 1.5
Thread Length C (mm)

15
Body Length D (mm)

51
Material

PA6 Plastic
OD Outside Diameter (mm)

34.5
ΦI Inside Diameter (mm)

25.5
ΦB Max Outer Diameter (mm)

44
Weight (kg|100)

2.4
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148414

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
