5020.037.216 / 15020037216 RQG-M M16 x 1.5 mm Metric FLEXAquick® Black straight connector for 15.8 mm OD conduit, IP68 sealing

Product Name:
5020.037.216 / 15020037216 RQG-M M16 x 1.5 mm Metric FLEXAquick® Black straight connector for 15.8 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020037216 Categories , , ,

The Flexaquick® RQG-M 15020037216 (Old Part Number 5020.037.216) is a straight Black plastic conduit connector with metric M16 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Choose from over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.





In Stock: 304
Stock: 304 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

304 in stock

Quantity Unit Price Ext. Price
1 US$5.73 US$5.73
5 US$5.56 US$27.79
10 US$5.44 US$54.44
15 US$5.16 US$77.36
25 US$4.87 US$121.76
50 US$4.58 US$229.20
100 US$4.30 US$429.75
250 US$4.01 US$1,002.75
500+ US$3.72 US$1,862.25+
Unit Cost : US$
Extended Cost : US$5.73
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-M
Part Number

15020037216
Part Number (Old)

5020.037.216
Colour

Black
Thread Type

Metric
Thread Size

M16 x 1.5
Thread Length C (mm)

11.5
Body Length D (mm)

39
Material

PA6 Plastic
OD Outside Diameter (mm)

15.8
ΦI Inside Diameter (mm)

11
ΦB Max Outer Diameter (mm)

23
Weight (kg|100)

0.7
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113148384

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
