5020.057.205 / 15020057205 RQW-N 1/2” NPT FLEXAquick® black 90° elbow connector for 15.8 mm OD conduit, IP68 sealing

Product Name:
5020.057.205 / 15020057205 RQW-N 1/2” NPT FLEXAquick® black 90° elbow connector for 15.8 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020057205 Categories , , ,

The Flexaquick RQW-N 15020057205 (Old Part Number 5020.057.205) is a Black plastic 90° elbow conduit connector with 1/2″ NPT outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-N 1/2″ NPT 90° elbow fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). View over 20 varieties of ROHRflex corrugated nylon conduits.

In Stock: 257
Stock: 257 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

257 in stock

Quantity Unit Price Ext. Price
1 US$10.14 US$10.14
5 US$9.84 US$49.18
10 US$9.63 US$96.33
15 US$9.13 US$136.89
25 US$8.62 US$215.48
50 US$8.11 US$405.60
100 US$7.61 US$760.50
250 US$7.10 US$1,774.50
500+ US$6.59 US$3,295.50+
Unit Cost : US$
Extended Cost : US$10.14
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQW-N
Part Number

15020057205
Part Number (Old)

5020.057.205
Colour

Black
Thread Type

NPT
Thread Size

1/2"
Thread Length C (mm)

12
Body Length D (mm)

42
Body Length E (mm)

40.5
Material

PA6 Plastic
OD Outside Diameter (mm)

15.8
ΦI Inside Diameter (mm)

14
ΦB Max Outer Diameter (mm)

23.5
Weight (kg|100)

1.1
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113174604

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
