5020.057.201 / 15020057201 RQW-N 1/4” NPT FLEXAquick® black 90° elbow connector for 10.0 mm OD conduit, IP68 sealing

Product Name:
5020.057.201 / 15020057201 RQW-N 1/4” NPT FLEXAquick® black 90° elbow connector for 10.0 mm OD conduit, IP68 sealing

Mfr. Part # 15020057201 Categories IBIS FLEXAquick Fitting 50 Pack, Plastic Body Fittings, Plastic Thread 90 Elbow, RQW-N

The Flexaquick RQW-N 15020057201 (Old Part Number 5020.057.201) is a Black plastic 90° elbow conduit connector with 1/4″ NPT outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQW-N 1/4″ NPT 90° elbow fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). View over 20 varieties of ROHRflex corrugated nylon conduits.

In Stock: 188

Stock: 188 can ship immediately

Factory Lead-Time: Can ship in 5 – 7 days

Minimum: 1

Multiples: 1

188 in stock

Quantity	Unit Price	Ext. Price
1	US$9.49	US$9.49
5	US$9.21	US$46.03
10	US$9.02	US$90.16
15	US$8.54	US$128.12
25	US$8.07	US$201.66
50	US$7.59	US$379.60
100	US$7.12	US$711.75
250	US$6.64	US$1,660.75
500+	US$6.17	US$3,084.25+

Unit Cost : US$

Extended Cost : US$9.49

Specifications

Package Size	50 pcs
Product Type	Plastic Body Fitting
Brand	Flexa
Family	RQW-N
Part Number	15020057201
Part Number (Old)	5020.057.201
Colour	Black
Thread Type	NPT
Thread Size	1/4"
Thread Length C (mm)	10
Body Length D (mm)	34
Body Length E (mm)	33
Material	PA6 Plastic
OD Outside Diameter (mm)	10
ΦI Inside Diameter (mm)	8.5
ΦB Max Outer Diameter (mm)	17
Weight (kg\|100)	0.4
IP Rating	IP 68 \| IP 69K
Low Temperature Rating (°C)	-40
High Temperature Rating (°C)	120
Customs Tariff Number	3917.40.0090
Country of Origin	Germany
GTIN / EAN Code	4025113176790
