Mfr. Part #
15020074236
Categories IBIS FLEXAquick Fitting 10 Pack, Metal Thread Straight, Plastic Body Fittings, RQGK-P
The Flexa RQGK-P 15020074236 (Old Part Number 5020.074.236) is described as a straight plastic conduit connector with PG 36 nickel-plated brass thread. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with both an O-ring (OR) and a flat sealing washer (FRH), EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity | Unit Price | Ext. Price |
---|---|---|
1 | US$72.31 | US$72.31 |
5 | US$65.08 | US$325.40 |
10 | US$57.85 | US$578.48 |
20 | US$54.23 | US$1,084.65 |
50+ | US$50.62 | US$2,530.85+ |
Unit Cost : US$
Extended Cost : US$72.31
Specifications
Product Type | Plastic Body Fitting |
---|---|
Brand | Flexa |
Family | RQGK-P |
Part Number | 15020074236 |
Part Number (Old) | 5020.074.236 |
Colour | Black |
Thread Type | PG |
Thread Size | 36 |
Thread Length C (mm) | 17. 0 |
Body Length D (mm) | 76. 0 |
Material | PA6 Plastic |
OD Outside Diameter (mm) | 42. 5 |
ΦI Inside Diameter (mm) | 36. 0 |
ΦB Max Outer Diameter (mm) | 63. 0 |
Weight (kg|100) | 13.1 |
Package Size | 10 pcs |
IP Rating | IP 68 | IP 69K |
Low Temperature Rating (°C) | -40 |
High Temperature Rating (°C) | 120 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- fit for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
