5107.034.240 / 15107034240 RQGK-M M40 x 1.5 mm FLEXAquick® straight metal thread connector for 34.5 mm OD conduit

Product Name:
5107.034.240 / 15107034240 RQGK-M M40 x 1.5 mm FLEXAquick® straight metal thread connector for 34.5 mm OD conduit

Flexa Logo
Mfr. Part # 15107034240 Categories , , ,

The Flexaquick RQGK-M 15107034240 (Old Part Number 5107.034.240) is a straight Black plastic conduit connector with metric M40 x 1.5 mm nickel-plated brass thread.

Thread length is 17.0 mm. Included with the fitting are both a Nitrile O-ring (OR-M) and a green Centellen flat sealing washer (FRH-M) for IP68/69K thread sealing.

The RQGK-M features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQGK-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.



In Stock: 24
Stock: 24 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

24 in stock

Quantity Unit Price Ext. Price
1 US$34.58 US$34.58
5 US$33.54 US$167.71
10 US$32.85 US$328.51
15 US$31.12 US$466.83
20 US$29.39 US$587.86
25 US$27.66 US$691.60
50 US$25.94 US$1,296.75
100 US$24.21 US$2,420.60
250+ US$22.48 US$5,619.25+
Unit Cost : US$
Extended Cost : US$34.58
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGK-M
Part Number

15107034240
Part Number (Old)

5107.034.240
Colour

Black
Thread Type

Metric
Thread Size

M40 x 1. 5
Thread Length C (mm)

17. 0
Body Length D (mm)

64. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

34. 5
ΦI Inside Diameter (mm)

27. 5
ΦB Max Outer Diameter (mm)

48. 0
Weight (kg|100)

6
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113211828

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
