5121.034.232 / 15121034232 RQBK90DR-M M32 x 1.5 mm swivel thread FLEXAquick 90 degree bend elbow connector for 34.5 mm OD conduit

Product Name:
5121.034.232 / 15121034232 RQBK90DR-M M32 x 1.5 mm swivel thread FLEXAquick 90 degree bend elbow connector for 34.5 mm OD conduit

Flexa Logo
Mfr. Part # 15121034232 Categories , , ,

The Flexa RQBK90DR-M 15121034232 (Old Part Number 5121.034.232) is a Black plastic 90° bend elbow conduit connector with swivelling metric M32 x 1.5 mm outer thread.

Highlights:

It features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQBK90DR-M conduit connector with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.

In Stock: 8
Stock: 8 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

8 in stock

Quantity Unit Price Ext. Price
1 US$51.53 US$51.53
5 US$46.38 US$231.89
10 US$41.22 US$412.24
20 US$38.65 US$772.95
50 US$36.07 US$1,803.55
100+ US$33.49 US$3,349.45+
Unit Cost : US$
Extended Cost : US$51.53
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQBK90DR-M
Part Number

15121034232
Part Number (Old)

5121.034.232
Colour

Black
Thread Type

Metric
Thread Size

M32 x 1. 5
Thread Length C (mm)

14. 0
Body Length E (mm)

91. 0
Body Length F (mm)

100. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

34. 5
ΦI Inside Diameter (mm)

24. 5
ΦB Max Outer Diameter (mm)

44. 0
Weight (kg|100)

16.5
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113213327

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening
  • swiveling also after installation

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
