Mfr. Part #
15011328020
Categories IBIS FLEXA US Fitting 50 Pack, Metal Body Fittings, Straight, US-M
The Flexa US-M 15011328020 (Old Part Number 5011.328.020) is a straight nickel-plated brass conduit connector with metric M20 x 1.5 mm outer thread.
This rugged, high-quality, machined nickel-plated brass conduit fitting features:
- pre-mounted outer “O” sealing ring made of NBR Perbunan Nitrile rubber
- TPE sealing ring
- brass ferrule
- highly secure compression style conduit connection
- grounding / bonding supported
- very good vibration and tension tolerance
Use with the following Flexa conduits:
- FLEXAgraff®-CU-AS (IP40 sealing level)
- SPR-CU-AS, SPR-EDU-AS (IP40 sealing level)
- FLEXAhightemp® (IP40 sealing level)
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-3 weeks
Minimum: 1
Multiples: 1
Quantity | Unit Price | Ext. Price |
---|---|---|
1 | US$48.08 | US$48.08 |
5 | US$46.64 | US$233.19 |
10 | US$45.68 | US$456.76 |
15 | US$43.27 | US$649.08 |
25 | US$40.87 | US$1,021.70 |
50 | US$38.46 | US$1,923.20 |
100 | US$36.06 | US$3,606.00 |
250+ | US$33.66 | US$8,414.00+ |
Unit Cost : US$
Extended Cost : US$48.08
Specifications
Product Type | Metal Body Fitting |
---|---|
Brand | Flexa |
Family | US-M |
Part Number | 15011328020 |
Part Number (Old) | 5011.328.020 |
Fits Conduit Types | FLEXAgraff-CU-AS, FLEXAhightemp, SPR-CU-AS, SPR-EDU-AS |
Thread Type | Metric |
Thread Size | M20 x 1.5 |
Thread Length C (mm) | 10 |
Body Length D (mm) | 33 |
Material | Ni-Brass |
OD Outside Diameter (mm) | 21 |
ΦI Inside Diameter (mm) | 16 |
ΦB Max Outer Diameter (mm) | 31 |
Weight (kg|100) | 3.94 |
Package Size | 50 pcs |
IP Rating | IP 40 |
Low Temperature Rating (°C) | -40 |
High Temperature Rating (°C) | 250 |
Data Sheet
Properties
- highly watertight and dustproof
- friction-type locking of conduit and screw connector
- correct grounding
- covering of the conduit ends
- vibration and tension proof
Applications
- machine and plant constructions
- automotive
- railway industry
- automation
- shipbuilding
- electrical installations
