Flexa USW-M 5010.539.032 / 15010539032 M32 x 1.5 mm nickel-plated brass 90° elbow connector for 27.0 mm OD conduit

Product Name:
Flexa USW-M 5010.539.032 / 15010539032 M32 x 1.5 mm nickel-plated brass 90° elbow connector for 27.0 mm OD conduit

Mfr. Part # 15010539032 Categories 90° Elbow Metal Body Fittings, IBIS FLEXA USW | USB Metal Elbow Fitting 10 Pack, Metal Body Fittings, USW-M

The Flexa USW-M 15010539032 (Old Part Number 5010.539.032) is a 90° elbow conduit connector made of nickel-plated brass with metric M32 x 1.5 outer thread.

This rugged, high-quality, machined conduit fitting features:

includes outer metric “O” sealing ring made of NBR Nitrile rubber
brass thrust collar with a brass or plastic ferrule
highly secure compression style conduit connection
grounding / bonding supported
very good vibration and tension tolerance

Use with the following Flexa conduits (IP40 sealing):

In Stock: 0

Stock: 0 can ship immediately

Factory Lead-Time: Can ship in 1 – 2 weeks

Minimum: 1

Multiples: 1

Quantity	Unit Price	Ext. Price
1	US$96.03	US$96.03
5	US$86.43	US$432.14
10+	US$76.82	US$768.24+

Unit Cost : US$

Extended Cost : US$96.03

Specifications

Package Size	10 pcs
Product Type	Metal Body Fitting
Brand	Flexa
Family	USW-M
Part Number	15010539032
Part Number (Old)	5010.539.032
Fits Conduit Types	FLEXAgraff-PU-AS, FLEXAgraff-PU-F
Thread Type	Metric
Thread Size	M32 x 1.5
Thread Length C (mm)	10
Body Length D (mm)	57
Material	Ni-Brass
OD Outside Diameter (mm)	27
ΦI Inside Diameter (mm)	22.5
ΦB Max Outer Diameter (mm)	39
Weight (kg\|100)	13.1
IP Rating	IP 40
Low Temperature Rating (°C)	-40
High Temperature Rating (°C)	125
