Mfr. Part #
AI10.012.030
Categories Sensors, Sensors, Vibration and Accelerometer Sensors
The IBIS Sensor # AI10.012.030 is a 10 mV/g, One Axis Accelerometer & Vibration Sensor, two bolt mount, 3.0 metre (9 ft) PUR Cable, Pigtail
In Stock: 0
Factory Lead-Time: Can Ship Immediately
Specifications
Product Type | Sensors |
---|---|
Brand | IBIS GmbH |
Family | Sensors |
Part Number | AI10.012.030 |
Housing Material | Stainless Steel/Nylon |
Weight (g) | 150 |
Connection | Pigtail |
IP Rating | IP67 |
Operating Temperature Range | -40 to +80 °C |
Sensor Type | Piezo Electric |
Number of Axes | 1 |
Sensitivity (mV/g) | 10 |
Resolution (g) | 0 |
Acceleration Max (g) | 500 |
Shock Resistance (g) | 5000 |
Frequency Response | 0.5Hz to 10kHz |
Spike Energy Measurement | 5kHz to 50kHz |
Cable Length/Type | 3.0 m PUR |
Data Sheet
Overview
- Full details coming soon
