Dietz Compact Light Curtain # LGTR-200-POK-ST4, 200 mm (8 inch) active height, PNP / NC output

Product Name:
Dietz Compact Light Curtain # LGTR-200-POK-ST4, 200 mm (8 inch) active height, PNP / NC output

Mfr. Part # LGTR-200-POK-ST4 Categories , ,

The Dietz LGTR-200-POK-ST4 is a 200 mm ( 8″) active height compact light curtain sensor with a digital PNP / NC output. The light grid features 200 scanning beams with a resolution down to 6 mm.
The T-profile housing simplifies installation and alignment. Hook-up wiring is quick via the attached 1.5 metre (5 ft) cable and M12 (4 wire) connector. For position sensing use ONLY. Do not use as a safety sensor.

In Stock: 0
Factory Lead-Time: Can Ship in 2 – 3 weeks
Quantity Unit Price Ext. Price
1+ US$649.60 US$649.60+
Unit Cost : US$
Extended Cost : US$649.6
Add to Quote

Specifications

Product Type

Sensors
Brand

Dietz
Family

Compact Light Curtains – Digital Output
Part Number

LGTR-200-POK-ST4
Light Source

Infrared LED Light
Resolution

6.0 mm
Housing Material

Aluminum | Black
Weight (g)

500
Switching Output

PNP NC
Sensitivity Adjustment

Potentiometer
Connection

Cable with M12
IP Rating

IP51
Operating Temperature Range

-10 to +50 °C
Active Zone Height

200 mm
Active Zone Range

0.2 m to 7.5 m

Data Sheet

Overview

  • Full details coming soon

Certifications
