5020.056.208 / 15020056208 RQG-N 1 1/2 ” NPT FLEXAquick® Black straight connector for 42.5 mm OD conduit, IP68 sealing

  • 5020.056.208 / 15020056208 RQG-N 1 1/2 " NPT FLEXAquick® Black straight connector for 42.5 mm OD conduit, IP68 sealing

Product Name:
5020.056.208 / 15020056208 RQG-N 1 1/2 ” NPT FLEXAquick® Black straight connector for 42.5 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020056208 Categories , , ,

The Flexaquick® RQG-N 15020056208 (Old Part Number 5020.056.208) is a straight Black plastic conduit connector with 1 1/2″ NPT outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-N 1 1/2” NPT straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Browse over 20 varieties of ROHRflex corrugated nylon conduits.

In Stock: 7
Stock: 7 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

7 in stock

Quantity Unit Price Ext. Price
1 US$22.54 US$22.54
5 US$21.86 US$109.32
10 US$21.41 US$214.13
15 US$20.29 US$304.29
20 US$19.16 US$383.18
25 US$18.03 US$450.80
50 US$16.91 US$845.25
100 US$15.78 US$1,577.80
250+ US$14.65 US$3,662.75+
Unit Cost : US$
Extended Cost : US$22.54
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-N
Part Number

15020056208
Part Number (Old)

5020.056.208
Colour

Black
Thread Type

NPT
Thread Size

1 1/2"
Thread Length C (mm)

18
Body Length D (mm)

55.5
Material

PA6 Plastic
OD Outside Diameter (mm)

42.5
ΦI Inside Diameter (mm)

36.5
ΦB Max Outer Diameter (mm)

55
Weight (kg|100)

3.5
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113173072

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
