5020.056.205 / 15020056205 RQG-N 1/2” NPT FLEXAquick® Black straight connector for 15.8 mm OD conduit, IP68 sealing

  • 5020.056.205 / 15020056205 RQG-N 1/2'' NPT FLEXAquick® Black straight connector for 15.8 mm OD conduit, IP68 sealing

Product Name:
5020.056.205 / 15020056205 RQG-N 1/2” NPT FLEXAquick® Black straight connector for 15.8 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020056205 Categories , , ,

The Flexaquick® RQG-N 15020056205 (Old Part Number 5020.056.205) is a straight Black plastic conduit connector with 1/2″ NPT outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG-N 1/2” NPT straight fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Browse over 20 varieties of ROHRflex corrugated nylon conduits.

In Stock: 227
Stock: 227 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

227 in stock

Quantity Unit Price Ext. Price
1 US$5.65 US$5.65
5 US$5.48 US$27.40
10 US$5.37 US$53.68
15 US$5.09 US$76.28
25 US$4.80 US$120.06
50 US$4.52 US$226.00
100 US$4.24 US$423.75
250 US$3.96 US$988.75
500+ US$3.67 US$1,836.25+
Unit Cost : US$
Extended Cost : US$5.65
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG-N
Part Number

15020056205
Part Number (Old)

5020.056.205
Colour

Black
Thread Type

NPT
Thread Size

1/2"
Thread Length C (mm)

11
Body Length D (mm)

39
Material

PA6 Plastic
OD Outside Diameter (mm)

15.8
ΦI Inside Diameter (mm)

12.5
ΦB Max Outer Diameter (mm)

25
Weight (kg|100)

0.7
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113173041

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
