5020.017.214 / 15020017214 RQB45-N 3/4″ NPT FLEXAquick® Black 45 degree elbow connector for 28.5 mm OD conduit, IP68

  • 5020.017.214 / 15020017214 RQB45-N 3/4" NPT FLEXAquick® Black 45 degree elbow connector for 28.5 mm OD conduit, IP68

Product Name:
5020.017.214 / 15020017214 RQB45-N 3/4″ NPT FLEXAquick® Black 45 degree elbow connector for 28.5 mm OD conduit, IP68

Flexa Logo
Mfr. Part # 15020017214 Categories , , ,

The Flexaquick® RQB45-N 15020017214 (Old Part Number 5020.017.214) is a Black plastic 45° elbow conduit connector with 3/4″ NPT outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQB45-N with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and new multi-layer conduits.

In Stock: 112
Stock: 112 can ship immediately
Factory Lead-Time: Can ship in 5 – 7 days
Minimum: 1
Multiples: 1

112 in stock

Quantity Unit Price Ext. Price
1 US$17.57 US$17.57
5 US$17.04 US$85.21
10 US$16.69 US$166.92
15 US$15.81 US$237.20
20 US$14.93 US$298.69
25 US$14.06 US$351.40
50 US$13.18 US$658.88
100 US$12.30 US$1,229.90
250+ US$11.42 US$2,855.13+
Unit Cost : US$
Extended Cost : US$17.57
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQB45-N
Part Number

15020017214
Part Number (Old)

5020.017.214
Colour

Black
Thread Type

NPT
Thread Size

3/4"
Thread Length C (mm)

13
Body Length E (mm)

68
Body Length F (mm)

68
Material

PA6 Plastic
OD Outside Diameter (mm)

28.5
ΦI Inside Diameter (mm)

17
ΦB Max Outer Diameter (mm)

37
Weight (kg|100)

2.6
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113202635

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
