Mfr. Part #
15020730040
Categories IBIS FLEXA USK & LKI Fitting 2 Pack, Plastic Body Fittings, Plastic Straight for AIRflex Conduits, USK-M
The Flexa USK-M 15020730040 (Old Part Number 5020.730.040) is a Grey plastic straight conduit connector with metric M40 x 1.5 mm thread, small pack.
This easy to install, compression style conduit fitting comes with an internal TPE rubber sealing ring and twist-in plastic ferrule.
Use with the following AIRflex® conduits:
- AIRflex-KUW-PVC-AS, AIRflex-KUW-PU-AS, AIRflex-K, AIRflex-GRS
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 2
Multiples: 2
Quantity | Unit Price | Ext. Price |
---|---|---|
2 | US$38.10 | US$76.21 |
4 | US$37.15 | US$148.61 |
6 | US$35.72 | US$214.34 |
8 | US$35.72 | US$285.78 |
Unit Cost : US$
Extended Cost : US$47.63
Specifications
Package Size | 2 pcs |
---|---|
Product Type | Plastic Body Fitting |
Brand | Flexa |
Family | USK-M |
Part Number | 15020730040 |
Part Number (Old) | 5020.730.040 |
Colour | Grey |
Thread Type | Metric |
Thread Size | M40 x 1.5 |
Thread Length C (mm) | 15 |
Body Length D (mm) | 51 |
Material | PP |
OD Outside Diameter (mm) | 45 |
ΦI Inside Diameter (mm) | 35 |
ΦB Max Outer Diameter (mm) | 63 |
Weight (kg|100) | 3.9 |
IP Rating | IP 54 |
Low Temperature Rating (°C) | -10 |
High Temperature Rating (°C) | 110 |
Data Sheet
Properties
- highly dust- and waterproof
- friction-type locking of conduit and screw connector
- vibration and tension-proof
Applications
- Machine and Plant Constructions
- Automation
- Electrical Installations
