5020.330.040 / 15020330040 USK-M M40 x 1.5 mm Flexa grey plastic straight connector for 45.0 mm OD AIRflex® conduits

Product Name:
5020.330.040 / 15020330040 USK-M M40 x 1.5 mm Flexa grey plastic straight connector for 45.0 mm OD AIRflex® conduits

Flexa Logo
Mfr. Part # 15020330040 Categories , , ,

The Flexa USK-M 15020330040 (Old Part Number 5020.330.040) is a Grey plastic straight conduit connector with metric M40 x 1.5 thread.

This easy to install, compression style conduit fitting comes with an internal TPE rubber sealing ring and twist-in plastic ferrule.

Use with the following Flexa AIRflex® flexible conduits (IP54 sealing):

Also available in a small 2 piece pack: Check here for USK-M small pack part # 5020.730.040



In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$41.29 US$41.29
5 US$40.05 US$200.26
10 US$39.23 US$392.26
15 US$37.16 US$557.42
20 US$35.10 US$701.93
25 US$33.03 US$825.80
50 US$30.97 US$1,548.38
100+ US$28.90 US$2,890.30+
Unit Cost : US$
Extended Cost : US$41.29
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

USK-M
Part Number

15020330040
Part Number (Old)

5020.330.040
Colour

Grey
Thread Type

Metric
Thread Size

M40 x 1.5
Thread Length C (mm)

15
Body Length D (mm)

51
Material

PP
OD Outside Diameter (mm)

45
ΦI Inside Diameter (mm)

35
ΦB Max Outer Diameter (mm)

63
Weight (kg|100)

3.9
IP Rating

IP 54
Low Temperature Rating (°C)

-10
High Temperature Rating (°C)

110
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113150653

Data Sheet

Properties

  • highly dust- and waterproof
  • friction-type locking of conduit and screw connector
  • vibration and tension-proof

Applications

  • Machine and Plant Constructions
  • Automation
  • Electrical Installations

Certifications
