5020.330.012 / 15020330012 USK-M M12 x 1.5 mm Flexa grey plastic straight connector for 14.0 mm OD AIRflex® conduits

Product Name:
5020.330.012 / 15020330012 USK-M M12 x 1.5 mm Flexa grey plastic straight connector for 14.0 mm OD AIRflex® conduits

Flexa Logo
Mfr. Part # 15020330012 Categories , , ,

The Flexa USK-M 15020330012 (Old Part Number 5020.330.012) is a Grey plastic straight conduit connector with metric M12 x 1.5 thread.

This easy to install, compression style conduit fitting comes with an internal TPE rubber sealing ring and twist-in plastic ferrule.

Use with the following Flexa AIRflex® flexible conduits (IP54 sealing):

Also available in a small 10 piece pack: Check here for USK-M small pack part # 5020.730.012



In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$8.25 US$8.25
5 US$8.00 US$40.01
10 US$7.84 US$78.38
15 US$7.43 US$111.38
25 US$7.01 US$175.31
50 US$6.60 US$330.00
100 US$6.19 US$618.75
250+ US$5.78 US$1,443.75+
Unit Cost : US$
Extended Cost : US$8.25
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

USK-M
Part Number

15020330012
Part Number (Old)

5020.330.012
Colour

Grey
Thread Type

Metric
Thread Size

M12 x 1.5
Thread Length C (mm)

12
Body Length D (mm)

43
Material

PP
OD Outside Diameter (mm)

14
ΦI Inside Diameter (mm)

8
ΦB Max Outer Diameter (mm)

25
Weight (kg|100)

0.7
IP Rating

IP 54
Low Temperature Rating (°C)

-10
High Temperature Rating (°C)

110
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113150608

Data Sheet

Properties

  • highly dust- and waterproof
  • friction-type locking of conduit and screw connector
  • vibration and tension-proof

Applications

  • Machine and Plant Constructions
  • Automation
  • Electrical Installations

Certifications
