Mfr. Part #
15020074213
Categories IBIS FLEXAquick Fitting 50 Pack, Metal Thread Straight, Plastic Body Fittings, RQGK-P
The Flexa RQGK-P 15020074213 (Old Part Number 5020.074.213) is described as a straight plastic conduit connector with PG 13.
5 nickel-plated brass thread. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with both an O-ring (OR) and a flat sealing washer (FRH), EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity | Unit Price | Ext. Price |
---|---|---|
1 | US$21.55 | US$21.55 |
5 | US$20.90 | US$104.52 |
10 | US$20.47 | US$204.73 |
15 | US$19.40 | US$290.93 |
25 | US$18.32 | US$457.94 |
50 | US$17.24 | US$862.00 |
100 | US$16.16 | US$1,616.25 |
250+ | US$15.09 | US$3,771.25+ |
Unit Cost : US$
Extended Cost : US$21.55
Specifications
Product Type | Plastic Body Fitting |
---|---|
Brand | Flexa |
Family | RQGK-P |
Part Number | 15020074213 |
Part Number (Old) | 5020.074.213 |
Colour | Black |
Thread Type | PG |
Thread Size | 13. 5 |
Thread Length C (mm) | 12. 0 |
Body Length D (mm) | 47. 5 |
Material | PA6 Plastic |
OD Outside Diameter (mm) | 18. 5 |
ΦI Inside Diameter (mm) | 12. 5 |
ΦB Max Outer Diameter (mm) | 29. 0 |
Weight (kg|100) | 2.3 |
Package Size | 50 pcs |
IP Rating | IP 68 | IP 69K |
Low Temperature Rating (°C) | -40 |
High Temperature Rating (°C) | 120 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- fit for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
