Flexa RQGK-P 5020.074.211 / 15020074211 PG11 straight metal thread connector for 15.8 mm OD conduit

Product Name:
Flexa RQGK-P 5020.074.211 / 15020074211 PG11 straight metal thread connector for 15.8 mm OD conduit

Flexa Logo
Mfr. Part # 15020074211 Categories , , ,

The FLEXAquick® RQGK-P 15020074211 (Old Part Number 5020.074.211) is a straight Black plastic conduit connector with PG 11 nickel-plated brass thread.

Included with the fitting are both a Nitrile O-ring (OR-P) and a green Centellen flat sealing washer (FRH-P) for IP68/69K thread sealing.

The RQGK-P features the FLEXAquick® quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQGK-P with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon conduits.



In Stock: 38
Stock: 38 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

38 in stock

Quantity Unit Price Ext. Price
1 US$13.79 US$13.79
5 US$13.38 US$66.88
10 US$13.10 US$131.01
15 US$12.41 US$186.17
25 US$11.72 US$293.04
50 US$11.03 US$551.60
100 US$10.34 US$1,034.25
250 US$9.65 US$2,413.25
500+ US$8.96 US$4,481.75+
Unit Cost : US$
Extended Cost : US$13.79
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGK-P
Part Number

15020074211
Part Number (Old)

5020.074.211
Colour

Black
Thread Type

PG
Thread Size

11
Thread Length C (mm)

12. 0
Body Length D (mm)

44. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

15. 8
ΦI Inside Diameter (mm)

11. 0
ΦB Max Outer Diameter (mm)

27. 0
Weight (kg|100)

2.2
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113177650

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
