Mfr. Part #
15020074209
Categories IBIS FLEXAquick Fitting 50 Pack, Metal Thread Straight, Plastic Body Fittings, RQGK-P
The Flexa RQGK-P 15020074209 (Old Part Number 5020.074.209) is described as a straight plastic conduit connector with PG 9 nickel-plated brass thread. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with both an O-ring (OR) and a flat sealing washer (FRH), EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity | Unit Price | Ext. Price |
---|---|---|
1 | US$15.65 | US$15.65 |
5 | US$15.18 | US$75.90 |
10 | US$14.87 | US$148.68 |
15 | US$14.09 | US$211.28 |
25 | US$13.30 | US$332.56 |
50 | US$12.52 | US$626.00 |
100 | US$11.74 | US$1,173.75 |
250+ | US$10.96 | US$2,738.75+ |
Unit Cost : US$
Extended Cost : US$15.65
Specifications
Product Type | Plastic Body Fitting |
---|---|
Brand | Flexa |
Family | RQGK-P |
Part Number | 15020074209 |
Part Number (Old) | 5020.074.209 |
Colour | Black |
Thread Type | PG |
Thread Size | 9 |
Thread Length C (mm) | 12. 0 |
Body Length D (mm) | 42. 0 |
Material | PA6 Plastic |
OD Outside Diameter (mm) | 13. 0 |
ΦI Inside Diameter (mm) | 8. 5 |
ΦB Max Outer Diameter (mm) | 24. 0 |
Weight (kg|100) | 1.6 |
Package Size | 50 pcs |
IP Rating | IP 68 | IP 69K |
Low Temperature Rating (°C) | -40 |
High Temperature Rating (°C) | 120 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- fit for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
