5105.028.232 / 15105028232 RQBK90-M M32 x 1.5 mm FLEXAquick® 90 degree bend elbow metal thread connector for 28.5 mm OD conduit

Product Name:
5105.028.232 / 15105028232 RQBK90-M M32 x 1.5 mm FLEXAquick® 90 degree bend elbow metal thread connector for 28.5 mm OD conduit

Flexa Logo
Mfr. Part # 15105028232 Categories , , ,

The Flexa RQBK90-M 15105028232 (Old Part Number 5105.028.232) is a Black plastic 90° bend elbow conduit connector with metric M32 x 1.5 nickel-plated brass thread.

Included with the fitting are both a Nitrile O-ring (OR-M) and a green Centellen flat sealing washer (FRH-M) for IP68/69K thread sealing.

The RQBK90-M features the FLEXAquick® quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for “Quick-connect on” assembly, or “Quick-disconnect off” disassembly. NO tools required!

Use the RQBK90-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex corrugated nylon PA6, PA12 and multi-layer conduits.





In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$32.29 US$32.29
5 US$31.32 US$156.61
10 US$30.68 US$306.76
15 US$29.06 US$435.92
20 US$27.45 US$548.93
25 US$25.83 US$645.80
50 US$24.22 US$1,210.88
100 US$22.60 US$2,260.30
250+ US$20.99 US$5,247.13+
Unit Cost : US$
Extended Cost : US$32.29
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQBK90-M
Part Number

15105028232
Part Number (Old)

5105.028.232
Colour

Black
Thread Type

Metric
Thread Size

M32 x 1. 5
Thread Length C (mm)

14. 0
Body Length E (mm)

85. 0
Body Length F (mm)

64. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

28. 5
ΦI Inside Diameter (mm)

20. 0
ΦB Max Outer Diameter (mm)

37. 0
Weight (kg|100)

6
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113211859

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • fit for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations
