2213.702.022 / 12213702022 Flexa SPR-PU-F 22.0 x 27.0 mm flexible liquidtight galvanized steel conduit, railway HL2/HL3 rated, black polyurethane (PU) protective jacket

Product Name:
2213.702.022 / 12213702022 Flexa SPR-PU-F 22.0 x 27.0 mm flexible liquidtight galvanized steel conduit, railway HL2/HL3 rated, black polyurethane (PU) protective jacket

Flexa Logo
Mfr. Part # 12213702022 Categories , , ,

The Flexa SPR-PU-F 12213702022 (Old Part Number 2213.702.022) is a 22.0 x 27.0 mm flexible liquidtight galvanized steel conduit that features an HL2/HL3 rated, black polyurethane (PU) flame retardant protective jacket.

The stretch-resistant, durable interlocked construction, and PU sheathing combine for outstanding mechanical, abrasion, and watertight protection of wires, cables, and fiber optic bundles.

Applications for SPR-PU-F conduits in the mass transit industry:

The SPR-PU-F conduit is ideal for railway and subway wire harness and cabling protection on passenger railway cars, subway cars, locomotives, buses and mass transit vehicles in general. Approvals and safety level ratings for low smoke emission, low toxicity, low flammability include: V0 (UL 94), EN 45545-2 (R22;HL2), (R23;HL3). Suitable for both indoor and outdoor wiring applications.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can Ship in 1 – 2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$1,502.30 US$1,502.30
2 US$1,427.19 US$2,854.37
5 US$1,352.07 US$6,760.35
10+ US$1,276.96 US$12,769.55+
Unit Cost : US$
Extended Cost : US$1502.3
Add to Quote

Specifications

Package Size

50m (164 ft) per roll
Product Type

Metal Conduit
Brand

Flexa
Family

SPR-PU-F
Part Number

12213702022
Part Number (Old)

2213.702.022
Colour

Black
OD Outside Diameter (mm)

27
ID Inside Diameter (mm)

22
Static Bend Radius (mm)

60
Dynamic Bend Radius (mm)

150
Weight (kg|m)

0.32
Material

Galvanized Steel, Jacket: PU
IP Rating

IP68
Low Temperature Rating (°C)

-50
High Temperature Rating (°C)

100
Extended Temperature (°C)

130
Flammability Rating (UL 94)

V0
Customs Tariff Number

83071000
Country of Origin

Germany
GTIN / EAN Code

4025113265999

Data Sheet

Properties

  • V0 according to UL 94
  • flame-retardant
  • self-extinguishing
  • weatherproof
  • widely resistant to seawater, acids and oils
  • free of halogen, silicone, cadmium
  • compression-resistant
  • approved acc. to DIN EN IEC 61386-23 DIN 5510, part 2 EN 45545-HL3 NFF 16-101, 102

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry – Heavy Mechanical Load
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
