dbk+4/3CFF/M18 E+S Microsonic Double Sheet Detector, 20–60 mm Range, 2 × Push-Pull Outputs, IO-Link

The dbk+4/3CFF/M18 E+S is a Microsonic ultrasonic double-sheet detection system for reliable identification of single sheets, double sheets and missing sheets in automated sheet-fed and material-handling applications. The transmitter sends an ultrasonic signal through the material to the receiver, allowing the system to detect multiple layers without relying on colour, print or optical contrast.

This standard M18 version operates with a 20–60 mm transmitter-to-receiver spacing, with an optimal spacing of 40 mm ±3 mm. It provides two Push-Pull switching outputs for double-sheet and missing-sheet signals and includes IO-Link for configuration, diagnostics and communication with compatible machine controls.

The dbk+4 family is well suited to paper and lighter sheet materials, including films, fine corrugated board, self-adhesive materials, wafers and similar sheet-fed products.

Applications

• Double-sheet detection
• Missing-sheet detection
• Sheet-fed printing equipment
• Paper handling systems
• Packaging machinery
• Print and converting machinery
• Collating and feeding systems
• Self-adhesive film processing
• Fine corrugated board handling
• Wafer and PCB handling
• IO-Link-enabled machine systems
