OGUL-121-G3-T3 di-soric 120 mm U-shaped visible red light laser fork barrier, Push-pull 100 mA NO/NC, IO-Link

The di-soric OGUL-121-G3-T3 is a compact, 120 mm U-shaped visible red light laser fork barrier engineered for ultra-precise, non-contact object detection in demanding industrial automation environments. Its focused visible red laser beam and its 0.05 mm resolution supports accurate detection of very small parts, edges, and labels, while the push-pull 100 mA NO/NC switchable output with IO-Link supports flexible integration, parameter setting, diagnostics, and easier machine changeover.

With its 120 mm fork opening, this model provides more clearance than smaller laser fork barriers while maintaining high-precision detection performance. It is suited to packaging, labeling, assembly, and converting applications where a wider sensing area is needed. The standard industrial housing is intended for general industrial machinery, unlike hygienic V4A variants designed for washdown or stainless-steel environments.

Key Features & Advantages

• Plug-and-play installation & easy device swapping: Integrated laser emitter and receiver are factory aligned, eliminating manual setup or calibration.

• Laser precision detection: Focused visible red laser light with resolution up to 0.05 mm enables pinpoint accuracy for minute objects, edges, and labels.

• Compact, rugged design: Ideal for tight installation spaces and industrial automation environments.

• Consistent performance: Reliable detection of reflective, transparent, or micro-scale targets.

• High-speed capability: Rapid response time ensures stable operation in high-speed production and labeling systems.

• IO-Link communication: Enables remote configuration, real-time diagnostics, and performance monitoring for smart integration.

• Durable construction: Built to resist vibration, contamination, and wear for long-term reliability.

• Extended service life: Non-contact sensing minimizes maintenance and downtime.

Typical Applications

• High-precision label and edge detection on packaging or converting lines

• Part counting and position control in filling or assembly systems

• Feed control and presence verification in robotic or bowl feeder setups

• Alignment and detection tasks requiring micron-level accuracy

• Paper, film, or foil web monitoring in printing or converting processes

Ideal For: Machine builders, OEMs, MRO, and system integrators requiring laser-precise, high-speed sensing for small-part, label, or edge detection in compact automation systems.
