di-soric OGWSD-100G3-T3 100 x 92 mm Frame light barrier, push-pull NO/NC output, IO-Link

The di-soric OGWSD-100G3-T3 is a 100 x 92 mm Frame / Window Sensor. Very fast, high resolution target detection, IO-Link equipped, static & dynamic switching, M8, 3-pin connection.

  • Output: Push-pull, 100 mA, NO/NC, switchable
  • IO-Link equipped, 4 operating modes for configuration and diagnosis
  • High resolution: 3.0 mm static operation, 2.5 mm dynamic operation
  • Fast response time: 0.05 ms
  • Pulse stretching: 0 … 150 ms adjustable
  • Robust metal frame housing with removable cross bar
  • Optics baffle protected
  • Potentiometer for adjustment
  • Operating principle: dynamic or static
  • Easy installation and hook-up via M8-3 pin connector

Detects most small to medium-sized metallic or non-metallic objects independent of target speed and surface features.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1 – 2 weeks
Quantity Unit Price Ext. Price
1+ US$1,123.69 US$1,123.69+
Unit Cost : US$
Extended Cost : US$1123.69
Add to Quote

Specifications

Product Type

Sensors

Brand

di-soric

Family

Static and Dynamic Sensing – IO-Link

Part Number

OGWSD-100G3-T3

Light Source

LED

Housing Material

Aluminum | Black

Weight (g)

300

Switching Output

Push-pull | 100 mA | NO/NC | switchable

Interface

IO-Link

Light Colour

Infrared

Sensitivity Adjustment

Potentiometer

Connection

M8 | 3-pin

IP Rating

IP67

Operating Temperature Range

0 to +60 °C

Part Number (Old)

OGWSD 100 P3K-TSSL | OGWSD 100 N3K-TSSL

Detection Area

100 x 92 mm

Dynamic Resolution

2.5 mm

Static Resolution

3.0 mm

Supply Voltage

18 to 30 VDC
