Flexa RQLG1-P 5515.054.248 / 15515054248
The Flexa RQLG1-P 15515054248 (Old Part Number 5515.054.248) is described as a straight plastic conduit connector with PG 48 outer thread. It features the Flexaquick quick connect system with an integrated snap-in sleeve with conical sealing.
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 5 weeks
Minimum: 1
Multiples: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | US$14.57 | US$14.57 |
| 5 | US$13.11 | US$65.57 |
| 10 | US$11.66 | US$116.56 |
| 20 | US$10.93 | US$218.55 |
| 50 | US$10.20 | US$509.95 |
| 100+ | US$9.47 | US$947.05+ |
Unit Cost : US$
Extended Cost : US$14.57
Specifications
| Package Size | 10 pcs |
|---|---|
| Product Type | Plastic Body Fitting |
| Brand | Flexa |
| Family | RQLG1-P |
| Part Number | 15515054248 |
| Part Number (Old) | 5515.054.248 |
| Colour | Black |
| Thread Type | PG |
| Thread Size | 48 |
| Thread Length C (mm) | 16 |
| Body Length D (mm) | 68 |
| Material | PA6 Plastic |
| OD Outside Diameter (mm) | 54.5 |
| ΦI Inside Diameter (mm) | 45 |
| ΦB Max Outer Diameter (mm) | 64 |
| Weight (kg|100) | 5.9 |
| IP Rating | IP 65 |
| Low Temperature Rating (°C) | -40 |
| High Temperature Rating (°C) | 120 |
| Customs Tariff Number | 3917.40.0090 |
| Country of Origin | Germany |
| GTIN / EAN Code | 4025113210401 |
Data Sheet
Properties
- resistant against oil and benzine
- highly resistant to acids and solvents
- free of silicone, cadmium, halogen
Applications
- Machine and Plant Constructions
- Automotive
- Automation
- Electrical Installations
Certifications
