5020.055.232 / 15020055232 RQG1-M M32 x 1.5 mm Metric FLEXAquick® Black straight connector for 34.5 mm OD conduit, IP66 sealing

Product Name:
5020.055.232 / 15020055232 RQG1-M M32 x 1.5 mm Metric FLEXAquick® Black straight connector for 34.5 mm OD conduit, IP66 sealing

Flexa Logo
Mfr. Part # 15020055232 Categories , , ,

The Flexaquick® RQG1-M 15020055232 (Old Part Number 5020.055.232) is a straight Black plastic conduit connector with metric M32 x 1.5 mm outer thread.

It features the Flexaquick® quick connect conduit fitting system with an integrated lock & release sleeve clip and built-in IP66 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQG1-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.

Need an alternate to the RQG1-M? Upgrade to the RQG-M, part number 5020.037.232, with a higher sealing level of IP68/69K (NEMA 6P). Check price and availability.

In Stock: 184
Stock: 184 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

184 in stock

Quantity Unit Price Ext. Price
1 US$11.32 US$11.32
5 US$10.98 US$54.90
10 US$10.75 US$107.54
15 US$10.19 US$152.82
20 US$9.62 US$192.44
25 US$9.06 US$226.40
50 US$8.49 US$424.50
100 US$7.92 US$792.40
250+ US$7.36 US$1,839.50+
Unit Cost : US$
Extended Cost : US$11.32
Add to Quote

Specifications

Package Size

25 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQG1-M
Part Number

15020055232
Part Number (Old)

5020.055.232
Colour

Black
Thread Type

Metric
Thread Size

M32 x 1.5
Thread Length C (mm)

15
Body Length D (mm)

51
Material

PA6 Plastic
OD Outside Diameter (mm)

34.5
ΦI Inside Diameter (mm)

25.5
ΦB Max Outer Diameter (mm)

44
Weight (kg|100)

2.4
IP Rating

IP 66
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113170941

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
