5020.090.216 / 15020090216 RQB90-P PG 16 FLEXAquick black 90 degree bend elbow connector for 21.2 mm OD conduit, IP68 sealing

Product Name:
5020.090.216 / 15020090216 RQB90-P PG 16 FLEXAquick black 90 degree bend elbow connector for 21.2 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15020090216 Categories , , ,

The Flexaquick RQB90-P 15020090216 (Old Part Number 5020.090.216) is a Black plastic 90° gentle smooth bend elbow conduit connector with European PG 16 outer thread.

It features the Flexaquick quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

This conduit connector installs in seconds for “Quick connect on” fitting and conduit assembly or “Quick disconnect off” fitting and conduit disassembly. NO tools required!

Use the RQB90-P PG16 thread 90° smooth bend elbow fitting with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Peruse the many ROHRflex multi-purpose and robotic grade corrugated nylon conduits.

In Stock: 146
Stock: 146 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1

146 in stock

Quantity Unit Price Ext. Price
1 US$10.44 US$10.44
5 US$10.13 US$50.63
10 US$9.92 US$99.18
15 US$9.40 US$140.94
25 US$8.87 US$221.85
50 US$8.35 US$417.60
100 US$7.83 US$783.00
250 US$7.31 US$1,827.00
500+ US$6.79 US$3,393.00+
Unit Cost : US$
Extended Cost : US$10.44
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQB90-P
Part Number

15020090216
Part Number (Old)

5020.090.216
Colour

Black
Thread Type

PG
Thread Size

16
Thread Length C (mm)

13
Body Length D (mm)

73
Body Length E (mm)

48
Material

PA6 Plastic
OD Outside Diameter (mm)

21.2
ΦI Inside Diameter (mm)

14.5
ΦB Max Outer Diameter (mm)

29.5
Weight (kg|100)

2.1
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113185495

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
