5103.010.012 / 15103010012 RQB90-M M12 x 1.5 mm Metric FLEXAquick® Grey 90 degree bend elbow connector for 10.0 mm OD conduit, IP68 sealing

Product Name:
5103.010.012 / 15103010012 RQB90-M M12 x 1.5 mm Metric FLEXAquick® Grey 90 degree bend elbow connector for 10.0 mm OD conduit, IP68 sealing

Flexa Logo
Mfr. Part # 15103010012 Categories , , ,

The Flexaquick® RQB90-M 15103010012 (Old Part Number 5103.010.012) is a Grey plastic 90° bend elbow conduit connector with metric M12 x 1.5 mm outer thread.

It features the Flexaquick® quick connect electrical conduit fitting system with an integrated lock & release sleeve clip and built-in IP68 sealing.

Installs in seconds for “Quick-connect on” fitting assembly or “Quick-disconnect off” fitting disassembly. NO tools required!

Use the RQB90-M with all fine or coarse corrugation plastic conduits of matching outside diameter (OD). Explore over 20 varieties of ROHRflex® corrugated nylon PA6, PA12 and multi-layer conduits.

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$9.62 US$9.62
5 US$9.33 US$46.66
10 US$9.14 US$91.39
15 US$8.66 US$129.87
25 US$8.18 US$204.43
50 US$7.70 US$384.80
100 US$7.22 US$721.50
250 US$6.73 US$1,683.50
500+ US$6.25 US$3,126.50+
Unit Cost : US$
Extended Cost : US$9.62
Add to Quote

Specifications

Package Size

50 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQB90-M
Part Number

15103010012
Part Number (Old)

5103.010.012
Colour

Grey
Thread Type

Metric
Thread Size

M12 x 1.5
Thread Length C (mm)

10
Body Length D (mm)

57
Body Length E (mm)

39
Material

PA6 Plastic
OD Outside Diameter (mm)

10
ΦI Inside Diameter (mm)

6.5
ΦB Max Outer Diameter (mm)

17
Weight (kg|100)

0.8
IP Rating

IP 68 | IP 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113191731

Data Sheet

Properties

  • resistant against oil and benzine
  • highly resistant to acids and solvents
  • free of silicone, cadmium, halogen

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
