Flexa RQGKZED-M 5133.034.240 / 15133034240
The Flexa RQGKZED-M 15133034240 (Old Part Number 5133.034.240) is described as a straight plastic conduit connector with metric M40 x 1.
5 nickel-plated brass thread and integrated cable strain relief. EMC shielding is provided through a bonding contact spring. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with a pre-mounted external O-ring. EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | US$156.44 | US$156.44 |
| 5 | US$140.80 | US$703.98 |
| 10 | US$125.15 | US$1,251.52 |
| 20 | US$117.33 | US$2,346.60 |
| 50 | US$109.51 | US$5,475.40 |
| 100+ | US$101.69 | US$10,168.60+ |
Unit Cost : US$
Extended Cost : US$156.44
Specifications
| Package Size | 10 pcs |
|---|---|
| Product Type | Plastic Body Fitting |
| Brand | Flexa |
| Family | RQGKZED-M |
| Part Number | 15133034240 |
| Part Number (Old) | 5133.034.240 |
| Colour | Black |
| Thread Type | Metric |
| Thread Size | M40 x 1. 5 |
| Thread Length C (mm) | 8. 0 |
| Body Length D (mm) | 79. 0 |
| Material | PA6 Plastic |
| OD Outside Diameter (mm) | 34. 5 |
| ΦI Inside Diameter (mm) | 27. 0 |
| ΦB Max Outer Diameter (mm) | 48. 0 |
| Weight (kg|100) | 13.4 |
| IP Rating | IP68 | 69K |
| Low Temperature Rating (°C) | -40 |
| High Temperature Rating (°C) | 120 |
| Gripping Range (mm) | 15. 0-25. 0 |
| Customs Tariff Number | 3917.40.0090 |
| Country of Origin | Germany |
| GTIN / EAN Code | 4025113308115 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- good for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
- optimal strain relief and sealing of cables at the same time
- bonding for EMC shielding
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
