Flexa RQGKZED-M 5133.028.232 / 15133028232
The Flexa RQGKZED-M 15133028232 (Old Part Number 5133.028.232) is described as a straight plastic conduit connector with metric M32 x 1.
5 nickel-plated brass thread and integrated cable strain relief. EMC shielding is provided through a bonding contact spring. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with a pre-mounted external O-ring. EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | US$85.32 | US$85.32 |
| 5 | US$76.79 | US$383.94 |
| 10 | US$68.26 | US$682.56 |
| 20 | US$63.99 | US$1,279.80 |
| 50 | US$59.72 | US$2,986.20 |
| 100+ | US$55.46 | US$5,545.80+ |
Unit Cost : US$
Extended Cost : US$85.32
Specifications
| Package Size | 10 pcs |
|---|---|
| Product Type | Plastic Body Fitting |
| Brand | Flexa |
| Family | RQGKZED-M |
| Part Number | 15133028232 |
| Part Number (Old) | 5133.028.232 |
| Colour | Black |
| Thread Type | Metric |
| Thread Size | M32 x 1. 5 |
| Thread Length C (mm) | 8. 0 |
| Body Length D (mm) | 73. 0 |
| Material | PA6 Plastic |
| OD Outside Diameter (mm) | 28. 5 |
| ΦI Inside Diameter (mm) | 20. 0 |
| ΦB Max Outer Diameter (mm) | 42. 8 |
| Weight (kg|100) | 12.7 |
| IP Rating | IP68 | 69K |
| Low Temperature Rating (°C) | -40 |
| High Temperature Rating (°C) | 120 |
| Gripping Range (mm) | 10. 0-19. 0 |
| Customs Tariff Number | 3917.40.0090 |
| Country of Origin | Germany |
| GTIN / EAN Code | 4025113308108 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- good for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
- optimal strain relief and sealing of cables at the same time
- bonding for EMC shielding
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
Certifications
