Flexa RQGKZED-M 5133.015.220 / 15133015220
The Flexa RQGKZED-M 15133015220 (Old Part Number 5133.015.220) is described as a straight plastic conduit connector with metric M20 x 1.
5 nickel-plated brass thread and integrated cable strain relief. EMC shielding is provided through a bonding contact spring. It features the Flexaquick quick connect system with an integrated snap-in & release sleeve and built-in sealing. It comes with a pre-mounted external O-ring. EN 45545-2 (HL3).
In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 1-2 weeks
Minimum: 1
Multiples: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | US$43.12 | US$43.12 |
| 5 | US$40.96 | US$204.82 |
| 10 | US$38.81 | US$388.08 |
| 15 | US$36.65 | US$549.78 |
| 20 | US$34.50 | US$689.92 |
| 40 | US$32.34 | US$1,293.60 |
| 100 | US$30.18 | US$3,018.40 |
| 250+ | US$28.03 | US$7,007.00+ |
Unit Cost : US$
Extended Cost : US$43.12
Specifications
| Package Size | 20 pcs |
|---|---|
| Product Type | Plastic Body Fitting |
| Brand | Flexa |
| Family | RQGKZED-M |
| Part Number | 15133015220 |
| Part Number (Old) | 5133.015.220 |
| Colour | Black |
| Thread Type | Metric |
| Thread Size | M20 x 1. 5 |
| Thread Length C (mm) | 6. 0 |
| Body Length D (mm) | 61. 0 |
| Material | PA6 Plastic |
| OD Outside Diameter (mm) | 15. 8 |
| ΦI Inside Diameter (mm) | 11. 0 |
| ΦB Max Outer Diameter (mm) | 27. 0 |
| Weight (kg|100) | 5.3 |
| IP Rating | IP68 | 69K |
| Low Temperature Rating (°C) | -40 |
| High Temperature Rating (°C) | 120 |
| Gripping Range (mm) | 3. 0-10. 0 |
| Customs Tariff Number | 3917.40.0090 |
| Country of Origin | Germany |
| GTIN / EAN Code | 4025113307873 |
Data Sheet
Properties
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- good for high mechanical stress
- impact-resistant
- tolerates high torque thread tightening
- optimal strain relief and sealing of cables at the same time
- bonding for EMC shielding
Applications
- Machine and Plant Constructions
- Automotive
- Railway Industry
- Shipbuilding
- Automation
- Electrical Installations
Certifications
