5111.054.250 / 15111054250 RQGKZE-M M50 x 1.5 mm FLEXAquick® straight metal thread bonding strain relief connector, 25.0 – 35.0 mm grip, for 54.5 mm OD conduit

Product Name:
5111.054.250 / 15111054250 RQGKZE-M M50 x 1.5 mm FLEXAquick® straight metal thread bonding strain relief connector, 25.0 – 35.0 mm grip, for 54.5 mm OD conduit

Flexa Logo
Mfr. Part # 15111054250 Categories , , ,

The Flexa RQGKZE-M 15111054250 (Old Part Number 5111.054.250) is a straight Black plastic conduit connector with metric M50 x 1.5 mm nickel-plated brass thread and integrated bonding cable strain relief.

EMC shielding is provided through the bonding nickel-plated brass strain relief.

Thread length = 9.0 mm, Cable clamping grip range = 25.0 – 35.0 mm. Included is a pre-mounted external O-ring.

The RQGKZE-M features the Flexaquick quick connect system with an integrated lock & release sleeve and built-in IP68 sealing. Installs in seconds for Quick “on” assembly, or Quick “off” disassembly. NO tools required!

Use with all fine or coarse corrugation plastic conduits of matching outside diameter (OD).

In Stock: 0
Stock: 0 can ship immediately
Factory Lead-Time: Can ship in 2-3 weeks
Minimum: 1
Multiples: 1
Quantity Unit Price Ext. Price
1 US$123.29 US$123.29
5 US$110.96 US$554.81
10 US$98.63 US$986.32
20 US$92.47 US$1,849.35
50 US$86.30 US$4,315.15
100+ US$80.14 US$8,013.85+
Unit Cost : US$
Extended Cost : US$123.29
Add to Quote

Specifications

Package Size

10 pcs
Product Type

Plastic Body Fitting
Brand

Flexa
Family

RQGKZE-M
Part Number

15111054250
Part Number (Old)

5111.054.250
Colour

Black
Thread Type

Metric
Thread Size

M50 x 1. 5
Thread Length C (mm)

9. 0
Body Length D (mm)

122. 0
Material

PA6 Plastic
OD Outside Diameter (mm)

54. 5
ΦI Inside Diameter (mm)

35. 5
ΦB Max Outer Diameter (mm)

68. 0
Weight (kg|100)

31.5
IP Rating

IP68 | 69K
Low Temperature Rating (°C)

-40
High Temperature Rating (°C)

120
Gripping Range (mm)

25. 0-35. 0
Customs Tariff Number

3917.40.0090
Country of Origin

Germany
GTIN / EAN Code

4025113196248

Data Sheet

Properties

  • resistant against oil and benzine
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • good for high mechanical stress
  • impact-resistant
  • tolerates high torque thread tightening
  • optimal strain relief and sealing of cables at the same time

Applications

  • Machine and Plant Constructions
  • Automotive
  • Railway Industry
  • Shipbuilding
  • Automation
  • Electrical Installations

Certifications
